330UPR – 330 Series Dual Channel Receiver

Discontinued

DISCONTINUED

Dual-channel. camera-mount UHF wireless receiver with digital display. Works with 2 transmitters simultaneously. Compatible with 35BT, 35HT, 35XT transmitters.

Features

Discrete 2-channel Camera-mount UHF Receiver
188 User-Selectable UHF Frequencies
New, Pivoting High-Gain Antenna
Digital LCD Display w/Multifunction Readout
3.5mm mini-jack output
Headphone Output on Receiver
Attached/Removable Shoe-Mount
Powered by 2 “AA” batteries
2 year warranty

Description

The 330UPR is a high quality dual-channel UHF camera-mount wireless receiver that features 188 user-selectable frequencies to assure you of always finding a “free” channel. It Includes pivoting high-gain antennas and an LCD digital display. The 330UPR can work with any two 300 Series transmitters simultaneously. Comes with a 3.5mm stereo output cable. The MX-2 Mini to XLR Stereo Y Cable can be purchased separately.

Frequency Range: UHF 188 Frequencies (566.125-589.875MHz)
Type of Reception: FM
Oscillator: PLL Synthesized
RF Squelch Level: -95dBm
Frequency Response: 50Hz – 15kHz
S/N Ratio: >84dB (100% Deviation)
Audio Out: MIC Level – Unbalanced – 3.5mm Mini-Jack
-28 dBm (100% Deviation – Mic Level)
Batteries: 2 “AA” Alkaline (2 x 1.5V) – 5-6 hours runtime
2 “AA” rechargeable Ni-MH (2 x 1.2V)
Dimen.: 2.87″W x 4.45″H x 1.59″D (73 x 113 x 40.5 mm)
Weight Approx.: 10.2 oz (290g) w/batteries
